1977 Chrysler Lebaron Diplomat Shop Service Repair Manual

This manual covers body, chassis, mechanical and electrical. It has sections on suspension, driveline/axle, brakes, engine, transmission, body, accessories, etc. This book includes wiring diagrams. Published by the factory, to provide information on diagnosis, service procedures, adjustments and specifications, there is none better. It is loaded with diagrams and illustrations to show you how to disassemble, repair and reassemble the various components and frequently gives troubleshooting information. Please note this is a supplement to the 1977 Chrysler Main Manual, and both books are needed to make a complete set.

---

• 1977 Chrysler
• Factory Authorized Reproduction
• Lebaron, Diplomat
• approx 289 pages
• Body, Chassis, Engine, Drivetrain & Electrical

---
